Product Details
We have 3 models for high speed & accurate weight grader: YGW-150F8/2, YGW-200F8/2, YGW-300F8/2. The corresponding weight checking range of each model: ≤1kg, ≤3kg, and ≤5kg. And the corresponding checking accuracy of each model: ±0.3g~±1g, ±1g~±3g, ±2g~±5g.
1. Easy detached belt for cleaning and maintenance.
2. Sorting level can be customized according to customer needs
3. The gentle plough steering arm is suitable for delicate and difficult-to-manage products.
4. Robust structure is easy to maintain
5. Full color touch screen with intelligent system is easy to use with user password protection, store up to 99 product setups.
6.Factory parameter reset function.
7.Manual or auto tare available, adjustable zero setting.
Specifications
| Brand: Foodman | Model: YGW-150F8/2 | Power Supply: AC220V±10% 50HZ（60HZ） |
| Rated Power: 0.4KW | Checking Range: ≤1000g | Accuracy: ±0.3g~±1g |
| Minimum Scale: 0.1g | Belt Speed: 60～90m/min | Suitable Product Dimension: ≤150mm (L)*100mm(W) |
| Weighing Belt Dimension: 300mm(L)*150mm(W) | Machine Dimension: 5145mm（L）*876mm（W）*1338mm（H） | Rejector: Swing Arm |
| Control Module: High Speed A/D Sampling Module | Product Preset: 100 | Conveyor Direction: From Left to Right ( or from Right to Left) |
| Compressed Air: 0.6-1 Mpa | Nozzle Connector Type: Φ10mm | Operating Temperature: 0℃～40℃ |
| Humidity: 30%～95% | Machine Body Construction: SUS304 Full Stainless Steel |
