Product Details
We have 3 models for this conveyor Weight Grader: YGW-LB200F8D, YGW-LB300F8D, YGW-LB350F8D. The corresponding weight checking range of each model: ≤3kg, ≤5kg, and ≤5kg. And the corresponding checking accuracy of each model: ±1g~±5g, ±2g~±5g, ±2g~±5g.
1. Easy detached belt for cleaning and maintenance.
2. Sorting level can be customized according to customer needs
3. The gentle plough steering arm is suitable for delicate and difficult-to-manage products.
4. Robust structure is easy to maintain
5. Full color touch screen with intelligent system is easy to use with user password protection, store up to 99 product setups.
6.Factory parameter reset function.
7.Manual or auto tare available, adjustable zero setting.
12.Accurate weighing with low frequency of calibration.
13.Manual or auto tare available, adjustable zero setting.
For this new year, we hope we can have more clients from all over the world, if we can become good partners for each other, please feel free to contact us and we will try to respond to you as soon as we can no matter how small your question is. We can provide customized services, and if you are interested in us, send us inquiries right away, and we will provide good services and attractive prices to you as much as we can. Looking forward to hearing from you, thank you very much!
Specifications
Brand: Foodman | Model: YGW-LB350F8D | Power Supply: AC220V±10% 50HZ(60HZ) |
Rated Power: 1.3KW | Checking Range: ≤5000g | Accuracy: ±2g~±5g |
Minimum Scale: 1g | Belt Speed: 60~90m/min | Suitable Product Dimension: ≤500mm (L)*330mm(W) |
Weighing Belt Dimension: 600mm(L)*340mm(W) | Machine Dimension: 9375mm(L)*1240mm(W)*1300mm(H) | Rejector: Swing Arm |
Control Module: High Speed A/D Sampling Module | Product Preset: 100 | Conveyor Direction: From Left to Right (From right to left optional) |
Compressed Air: 0.6-1 Mpa | Nozzle Connector Type: Φ10mm | Operating Temperature: 0℃~40℃ |
Humidity: 30%~95% | Machine Body Construction: SUS304 Full Stainless Steel |
